High Current Mains Switching with Over Current and Over Voltage Protection
Tongou TO-Q-SY2-JZT
The TO-Q-SY2-JZT DIN Rail high current mains switch features a software driven over current circuit breaker and over/under voltage protection.
- On/Off Switching via IoT Portal App
- Over Current Circuit Breaker
- Receive SMS/Calls (from IoT Portal) on circuit tripping
- Over/Under Voltage Protection
- Adjust over current/voltage via IoT Portal App
- Power Measurement
- Energy Consumption
- Monitor Internal Temperature
Always use an electro-mechanical circuit breaker or fuse in series with this device!
Specification
- Working voltage : AC90-280V, 50 / 60Hz
- Rate Current : (1-63A)adjustable
- Over-voltage protection : 220-265V
- Unde-voltage protection : 76-240V
- Temperature protection : 40-100℃
Can be ordered when out of stock for 7 day delivery
